Title: polyester filter fabric used in mine industry
Key words: polyester filter mesh filter mesh belt
Our filter cloth can be customized and converted to fit any manufacturer’s filter press, no matter the size or shape. We make sure that all of our filter cloth for filter press systems are carefully selected and optimized
Features
1) Available in PA, PET, PP, PVDF, or as required.
2) Ease of cleaning.
3) Customized designs, shapes and materials possible.
4) Max temperature 130℃, acid and alkali resistant.
5) Sealant steel or plastic ring, adjusted to various types of equipment.
THE FILTER CLOTH WHICH CAN BE APPLIED IN VARIOUS INDUSTRY | ||||||
No. | Product Name | Material | Weight (g/m2) | Thickness (mm) | AirPermeability (L/M2/S) | Applied Industry |
01 | JJ1515 | Polypropyllenemonofilament | 350 | 0.55 | 80 | Diatomite |
02 | 1323 | Polypropyllenemonofilament | 390 | 0.65 | 315 | Pyrohydrolysis, Anaerobic Sewage |
03 | JJ1542 | Polypropyllenemonofilament | 360 | 0.5 | 50 | White carbon black |
04 | JJ1520 | Polypropyllenemonofilament | 380 | 0.65 | 160 | Specialized for sewage-automic Cake discharge |
05 | Specialized for beer | Polypropyllenemonofilament | 335 | 0.65 | 950 | Specialized for beer |
06 | JJ1540 | Polypropyllenemonofilament | 327 | 0.75 | 570 | Aluminium oxide-vertical disc filter |
07 | JJ2915 | Polypropyllenemonofilament | 334 | 0.55 | 195 | Bentonite |
08 | PA2026 | Polyamide monofilament | 425 | 0.62 | 900 | Coal washing |
09 | JJ1570 | Polyamide monofilament | 306 | 0.4 | 550 | Palm oil |
10 | 5536 | Polyamide monofilament | 270 | 0.4 | 380 | Rice syrup oil |
11 | Twill silk screen | Polyamide monofilament | 250 | 0.52 | 3200 | Alcohol,citric acid, aluminite powder |
12 | 80mesh silk screen | Polyamide monofilament | 140 | 0.26 | 4300 | Alcohol, citric acid |
13 | JJ2222 | Polyamide monofilament | 665 | 1 | 230 | Specialized for titanium dioxide waste water(one-time open) |
14 | New type 2026 | Polyamide monofilament | 464 | 0.76 | 1800 | Municipal sewage, coal washing |
15 | JJ2630 | Polyamid/polypropylene monofilament | 480 | 0.86 | 600 | Specialized for sewage-automatic cake discharge |
16 | Thickened JJ2245 | Polyamid6/polyamide66 monofilament | 395 | 0.6 | 1150 | Aluminium oxide-flat disc filter |
Packing detail:
1.We always use poly bag for the goods which ship by air, so that customer can save freight free.
2.Wooden case is the best for ocean shipment, because it can effective avoid the damage during shipping.
3.There also have some customer request us to use the carton to packing their goods.
4.We can according to customer's requirement.
